ARC FRP Structural Profile

FRP Structural Profiles are as strong as traditional materials such as steel, timber, and aluminium. In fact, they are highly superior compared with other traditional materials as they are lightweight, corrosion resistant, fire retardant, and much more. They are also cost-effective with low installation costs and little to no maintenance required. These ready-made construction profiles can be sourced within your construction schedule.

FRP Structural Profiles are manufactured using the pultrusion process. Glass mat and rovings are drawn through a resin bath and pulled into a heated die to form the required shape. This process allows for the production of a vast array of structural shapes.

We also offer a custom design and FRP fabrication service based on your unique needs. Whether it is a small project or a large-scale installation, our experienced Engineers and Technicians are ready to help you by providing specially designed, top-quality FRP products to suit your specifications.

frp structural profile
frp structural shape
01

High Tensile Strength

02

Anti Corrosion

03

Low Maintenance

04

Non-Conductive

05

Chemical Inertness

Advantages of ARC FRP Structural Profile

Corrosion Resistance

Corrosion resistance

FRP structural profiles are highly resistant to corrosion caused by various environmental factors, such as moisture, chemicals, and atmospheric pollutants. This resistance ensures a longer service life and reduces maintenance costs compared to traditional metallic structural profiles, which are susceptible to corrosion.

Lightweight and High Strength

High strength-to-weight ratio

FRP structural profiles possess excellent strength-to-weight ratios, making them lightweight yet strong. This characteristic facilitates easier handling, transportation, and installation, while also reducing the load on supporting structures.

Low thermal conductivity

Low thermal conductivity

FRP structural profiles have low thermal conductivity, which can provide insulation properties and reduce thermal bridging, making them suitable for applications where temperature control or energy efficiency is important.

Electromagnetic transparency

Electromagnetic transparency

FRP structural profiles are non-conductive and transparent to electromagnetic fields, making them suitable for applications in environments where electrical or electromagnetic interference is a concern, such as in electrical substations or communication towers.

Chemical Resistance

Chemical resistance

FRP structural profiles are resistant to a wide range of chemicals, making them suitable for use in chemical plants, laboratories, and other industrial environments where chemical exposure is a concern.

Low Maintenance

Low maintenance

FRP structural profiles are resistant to fouling, scaling, and buildup, which can reduce the need for frequent cleaning and maintenance, resulting in lower operational costs.

Versatility

Versatility

FRP structural profiles can be manufactured in various shapes, sizes, and configurations, allowing for customization to meet specific application requirements, such as beams, columns, trusses, or frames.

Durability

Durability

FRP structural profiles are resistant to environmental factors such as UV radiation, temperature fluctuations, and moisture, ensuring long-lasting performance in both indoor and outdoor installations.

Non magnetic

Non-magnetic

FRP structural profiles are non-magnetic, making them suitable for applications where magnetic interference or compatibility is a concern, such as in medical facilities or certain industrial processes.

Aesthetic versatility

Aesthetic versatility

FRP structural profiles can be manufactured in various colors and finishes, allowing for integration with different architectural or design requirements.

TECHNICAL SPECIFICATIONS

  • Minimum Ultimate Coupon Properties (UN)

    Ultimate Coupon Properties Test Method Units Square Tube Values Round Tube Values
    Tensile Stress, LW ASTM D 638 psi 30000 30000
    N/mm² 207 207
    Tensile Modulus, LW ASTM D 638 106 psi 2.5 2.5
    103 N/mm² 17.2 17.2
    Compressive Stress, LW ASTM D 695 psi 30000 30000
    N/mm² 207 207
    Compressive Modulus, LW ASTM D 695 106 psi 2.5 2.5
    103 N/mm² 17.2 17.2
    Flexural Stress, LW ASTM D 790 psi 30000 30000
    N/mm² 207 207
    Flexural Modulus, LW ASTM D 790 106 psi 1.6 1.6
    10³ N/mm² 11.0 11.0
    Short Beam Shear, LW ASTM D 2344 psi 4500 4500
    N/mm² 31 31
    Density ASTM D 792 Lbs/in³ 0.060 0.060
    N/mm² 0.0000163-0.0000193 0.0000163-0.0000193
    Water Absorption % 24 Hrs. In water ASTM D 570 % max by wt. 0.6 0.6
    Coefficient Of Thermal Expansion, LW ASTM D 696 10-6 in/in/°F 7 7
    10-5mm/mm/°C 1.2 1.2
